PanTINT® Ultimate 2 Series
Chip Dispersions for Waterborne Applications
PanTINT® Ultimate 2 Series Chip Dispersions are dry, powdered colorants free from alkylphenolethoxylates, solvents or other hazardous ingredients. PanTINT® Ultimate dispersions have much finer pigment particle size than is normally achieved in most standard dispersion processes. They are granulated for ease of handling and incorporation with minimal dusting. PanTINT ® Ultimate Dispersions are stable under normal ambient conditions and will not sinter, agglomerate or lose strength on aging.
- Solvent Free
- Zero VOC
- APE free
- High pigment concentration – 65-75% pigment
- Exceptional color strength – 10 to 15% greater than comparable liquid dispersions at equal pigment level
- Fast incorporation
- Mean pigment particle size < 0.5 micron
- Full development of hue and tone
- Stable on aging
- Little or no viscosity change in finished coating
Recommended Use
PanTINT® Ultimate Chip Dispersions are designed for use in most aqueous systems, including architectural and industrial coatings, automotive refinish, printing inks, ink jet inks, textile finishes and related applications. The high pigment concentration allows use of PanTINT® Ultimate in masstone and deep color applications with minimal or no effect on your product's performance properties.
Typical Values
| STANDARD PRODUCT DESCRIPTION | COMPOSITION % BY WEIGHT | COMPOSITION % BY VOLUME | DENSITY | |||||
|---|---|---|---|---|---|---|---|---|
| Code | Pigment | CI Name | Pigment | Vehicle | Pigment | Vehicle | lb/gal | Sp. Gr. |
| 2W1113P | Titanium White | W 6 | 74.0 | 26.0 | 47.2 | 52.8 | 21.02 | 2.52 |
| 2B1244P | Phthalo Blue RS | B 15:2 | 66.0 | 34.0 | 58.8 | 41.2 | 13.52 | 1.62 |
| 2B1247P | Phthalo Blue GS | B 15:3 | 65.0 | 35.0 | 60.5 | 39.5 | 12.02 | 1.44 |
| 2G1739P | Phthalo Green | GR 7 | 65.0 | 35.0 | 61.2 | 39.8 | 11.74 | 1.41 |
| 2K1368P | Masstone Black | BK 7 | 60.0 | 40.0 | 51.3 | 48.7 | 12.82 | 1.54 |
| 2K1380P | Tinting Black | BK 7 | 65.0 | 35.0 | 57.3 | 42.7 | 13.24 | 1.59 |
| 2R1606P | DPP Red YS | R 254 | 67.0 | 33.0 | 59.9 | 40.1 | 13.75 | 1.65 |
| 2R1645P | Naphthol Red BS | R 170 | 68.0 | 32.0 | 69.5 | 30.5 | 10.32 | 1.24 |
| 2R1602P | Quinacridone Magenta | R 122 | 65.0 | 35.0 | 61.4 | 38.6 | 11.26 | 1.35 |
| 2V1862P | Carbazole Violet | V 23 | 65.0 | 35.0 | 61.0 | 39.0 | 11.71 | 1.40 |
| 2Y1435P | Diarylide Yellow AAOT | Y 14 | 67.0 | 33.0 | 65.1 | 34.9 | 11.33 | 1.36 |
| 2Y1444P | Benzamidazolone Yellow | Y 151 | 67.0 | 33.0 | 62.1 | 37.9 | 11.59 | 1.39 |
| 2Y1446P | Diarylide Yellow RS | Y 83 | 67.0 | 33.0 | 63.8 | 36.2 | 11.83 | 1.42 |
Incorporation
The PanTINT Ultimate 2 Series is formulated to be soluble in most aqueous systems. The colorants can be fully incorporated with easy mixing within 5 to 10 minutes, using high sheer disperser, paddle mixer or paint shaker.
