PanTINT® 18 Series
Chip Dispersions for Waterborne Coatings and Inks
High strength 100% solid colorants with broad compatibility in a wide variety of conventional, low and zero VOC water based coatings and inks. Pigments used in PanTINT 18 Series have been selected to meet the durability and transparency requirements of most high performance applications.
Recommended Use
PanTINT 18 Colorants can be used for tinting and masstone applications in most waterborne ambient cured and baking finishes including:
- Appliance Finishes
- Industrial Maintenance Coatings
- Machinery and Implement Enamels
- Water Gravure Inks
- Wood Finishes
- Transportation Coatings
- Aerosol Paints
- Automotive Refinish Coatings
- Marine Coatings
- Aerospace Coatings
- Adhesive Tapes
Compatibility
- Water Reducible
- Acrylic
- Alkyd
- Polyester
- Epoxy
- 2K Polyurethane
- Emulsion
- Acrylic
- Styrene Acrylic
- Polyvinyl Acrylic
- Polyvinyl Acetate
- Styrene Butadiene
- Polyurethane PUD
Typical Values
| STANDARD PRODUCT DESCRIPTION | COMPOSITION
% BY WEIGHT |
COMPOSITION
% BY VOLUME |
DENSITY | |||||
|---|---|---|---|---|---|---|---|---|
| Code | Pigment | CI Name | Pigment | Vehicle | Pigment | Vehicle | lb/gal | Sp. Gr. |
| 18B1252 | Phthalo Blue RS | B 15:2 | 53.0 | 47.0 | 44.1 | 55.9 | 11.32 | 1.36 |
| 18B1203 | Phthalo Blue GS | B 15:3 | 54.0 | 46.0 | 46.5 | 53.5 | 11.17 | 1.34 |
| 18G1701 | Phthalo Green | G 7 | 54.0 | 46.0 | 39.1 | 60.9 | 12.73 | 1.53 |
| 18K1302 | Masstone Black | BK 7 | 52.5 | 47.5 | 41.0 | 59.0 | 11.85 | 1.42 |
| 18K1331 | High Jet Black | BK 7 | 31.0 | 69.0 | 22.2 | 77.8 | 10.83 | 1.30 |
| 18K1366 | Tinting Black | BK 7 | 52.5 | 47.5 | 41.0 | 59.0 | 11.85 | 1.42 |
| 18Q1964 | Diarylide Orange | OR 34 | 53.0 | 47.0 | 47.6 | 52.4 | 10.61 | 1.27 |
| 18R1654 | Lithol Rubine | R 57:1 | 59.0 | 41.0 | 49.6 | 50.4 | 11.70 | 1.40 |
| 18R1658 | Red Oxide Medium Dark | R 101 | 56.7 | 43.3 | 24.9 | 75.1 | 16.64 | 1.99 |
| 18R1657 | Transparent Red Oxide | R 101 | 56.7 | 43.3 | 27.7 | 72.3 | 15.99 | 1.92 |
| 18R1661 | Napthol Red BS | R 170 | 53.0 | 47.0 | 48.4 | 51.6 | 10.42 | 1.25 |
| 18R1667 | Napthol Red YS | R 170 | 56.7 | 43.3 | 27.1 | 72.9 | 10.65 | 1.28 |
| 18V1901 | Carbazole Violet | V 23 | 54.0 | 46.0 | 47.1 | 52.9 | 10.99 | 1.32 |
| 18W1162 | Titanium Dioxide | WH 6 | 57.7 | 43.3 | 27.1 | 72.9 | 16.13 | 1.93 |
| 18W1168 | Titanium Dioxide-Chalk Resistant | WH 6 | 57.7 | 43.3 | 27.4 | 72.6 | 16.07 | 1.93 |
| 18Y1456 | Yellow Oxide | Y 42 | 56.7 | 43.3 | 26.6 | 73.4 | 16.24 | 1.95 |
| 18Y1455 | Transparent Yellow Oxide GS | Y 42 | 56.7 | 43.3 | 28.2 | 71.8 | 15.90 | 1.91 |
| 18Y1408 | Isoindolinone Yellow
|
Y 110
|
53.0 | 47.0 | 48.5 | 51.5 | 10.48 | 1.26 |
| 18Y1435 | Isoindolinone Yellow | Y 110 | 49.0 | 51.0 | 37.6 | 62.4 | 11.72 | 1.40 |
| 18Y1460 | Hansa Yellow | Y 74 | 53.0 | 47.0 | 48.4 | 51.6 | 10.43 | 1.25 |
| 18Y1463 | AAOT Yellow | Y 14 | 53.0 | 47.0 | 26.6 | 73.4 | 10.60 | 1.27 |
Incorporation
PanTINT®18 powder pigment dispersions are based on a water soluble acrylic resin. They are incorporated into aqueous systems with a constant pH above 9. Complete incorporation may take 30 - 60 minutes. Vigorous agitation and elevated temperatures will increase the speed of solution.
